Single mode aerial overhead outdoor ADSS 8 12 core 3km fiber optic cable for sale

Brand Name : EBOCOM

Model Number : ADSS -120B1.3

Certification : ISO TLC

Place of Origin : Shandong，China

MOQ : 2000M

Price : EXW ≥2000m $0.99/M ≥5000m $0.97/M

Payment Terms : T/T

Supply Ability : 50000KMS/day

Packaging Details : 1. Iron-wooden drum or non-fumigation wooden drum,normal wooden drum. 2. Drum size can be designed,details will calculation for suitable for containers.

MODEL : Ebo-ADSS

Cable Length : 3Km/Drum

Fiber : SM G652D

Insertion Loss : ≤0.30dB

Strengthen : Aramid Yarn

Return Loss : ≥50dB

Jacket Diameter : According to the structure

Durability : ≤0.20dB

Jacket Material : PE

Test Wavelength : 1310/1550nm

Contact Now

Central loose tube optical fiber

Metallic central reinforcer

Fill gel into SZ stranded cores

Two-sided plastic-coating longitudinally-wrapped steel tape

Low-smoke zero halogen flame-retardant sheath

Application Range:

Suitable for long-distance communication and interoffice communication

Laying Method:Pipeline, aerial

Applicable Temperature:-40ºC~+60ºC

Product Features:

1.Low optical fiber transmission loss and low dispersion.

2.Endow cables with excellent mechanical properties and environmental performance due to reasonable design and precise control over excess length of optical fibers in loose tube and cabling mode.

3.Keep structure compact, and protect the cable from stress under hostile environment by use of SZ stranded structure.

4.Fill waterproof cable gel outside the reinforcer and inside cores, ensuring its moisture proof and water proof effect.

5.Excellent flexibility and bending resistance performance.

6.Provide more excellent moisture proof effect as well as bullet proof function as the cores are wrapped longitudinally by steel tape.

7.The cable sheath is made from halogen-free flame retardant polyethylene materials, with excellent flame retardant effect, no toxicity and pollution.

Technical Parameters

Fiber cores Outer diameter
of optical cable
mm		 Weight of
optical cable
kg/km		 Minimum bending
radius mm		 Allowable minimum
tensile strength N		 Allowable minimum
crush resistance mN/100mm
Static Dynamic Short-term Long-term Short-term Long-term
2~36 11.8 190 120 240 1500 600 1000 300
38~72 13.4 225 140 280 1500 600 1000 300
74~96 14.9 266 160 320 1500 600 1000 300
98~120 16.6 350 170 340 1500 600 1000 300
122~144 18.2 400 190 380 1500 600 1000 300
